Name: IPD50N06S4-09 TO-252 Integrated circuit chip IC brand new original unused
Brand: INFINEON
SKU: IPD50N06S4-09
Rating: 5 (133 reviews)

Home > Products > Ic Integrated Circuit >

IPD50N06S4-09 TO-252 Integrated circuit chip IC brand new original unused

Place of Origin:

original

Brand Name:

INFINEON

Model Number:

IPD50N06S4-09

Request A Quote

Product Details

Quality：:

Brand New Unused

Package / Box::

TO-252

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Price

Negotiate

Packaging Details

4000

Delivery Time

Stock

8000+

Payment Terms

D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

97830pcs

BSP613PH6327 SOT223 Integrated Circuit Ic Chip

Get Best Price

Video

IPD100N04S402ATMA1 Integrated Power Ic TO-252

Get Best Price

Video

IPD320N20N3G Ic Integrated Circuit TO-252

Get Best Price

Video

IPD90P04P4L-04 TO-252 Ic Integrated Circuit In Motor Drivers

Get Best Price

+8613380499166

kezhiwei@lianyixinic.com

Contact Now

Product Description

ISO9001.pdf

Application: IPD50N06S4-09 is an N-channel MOSFET suitable for high-speed switching applications such as DC-DC converters, motor drivers, etc.
Conclusion: IPD50N06S4-09 has the characteristics of low conduction resistance, fast switching speed, and high current carrying capacity, which can improve system efficiency and reliability.
Parameters:
Maximum drain source voltage: 60V
Maximum drain current: 50A
Maximum power consumption: 143W
Conduction resistance: 9.5m Ω
Switching time: 13ns
Charging time: 60ns
Discharge time: 41ns
Gate drive voltage: ± 20V
Working temperature range: -55 ℃~175 ℃
Packaging: IPD50N06S4-09 is packaged as TO-252-3, also known as DPAK, with dimensions of 6.5mm x 9.5mm x 2.3mm, suitable for surface mount.

Product Technical Specifications

EU RoHS	Compliant with Exemption聽
ECCN (US)	EAR99
Part Status	Active
HTS	8541.29.00.95
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	Yes
PPAP	Unknown
Product Category	Power MOSFET
Configuration	Single
Process Technology	OptiMOS
Channel Mode	Enhancement
Channel Type	N
Number of Elements per Chip	1
Maximum Drain Source Voltage (V)	60
Maximum Gate Source Voltage (V)	卤20
Maximum Gate Threshold Voltage (V)	4
Maximum Continuous Drain Current (A)	50
Maximum Gate Source Leakage Current (nA)	100
Maximum IDSS (uA)	1
Maximum Drain Source Resistance (mOhm)	9@10V
Typical Gate Charge @ Vgs (nC)	36@10V
Typical Gate Charge @ 10V (nC)	36
Typical Input Capacitance @ Vds (pF)	2911@25V
Maximum Power Dissipation (mW)	71000
Typical Fall Time (ns)	5
Typical Rise Time (ns)	40
Typical Turn-Off Delay Time (ns)	20
Typical Turn-On Delay Time (ns)	15
Minimum Operating Temperature (掳C)	-55
Maximum Operating Temperature (掳C)	175
Supplier Temperature Grade	Automotive
Packaging	Tape and Reel
Maximum Pulsed Drain Current @ TC=25掳C (A)	200
Mounting	Surface Mount
Package Height	2.41(Max)
Package Width	6.22(Max)
Package Length	6.73(Max)
PCB changed	2
Tab	Tab
Standard Package Name	TO-252
Supplier Package	DPAK
Pin Count	3
Lead Shape	Gull-wing
