Place of Origin:
original
Brand Name:
TI
Model Number:
DAC7571IDBVR
Contact Us
Application:
The DAC7571IDBVR is a low-power, 16 bit accuracy, single channel digital to analog converter (DAC). It is commonly used in fields such as industrial automation, testing and measurement, audio equipment, and communication systems.
Conclusion:
The DAC7571IDBVR can convert digital signals into analog signals and output them to external circuits. It has the advantages of high accuracy, low noise, and low drift, and can provide high-quality analog signal output. In addition, the DAC7571IDBVR also has the characteristics of low power consumption and small size, which can be flexibly applied in various applications.
Parameters:
Resolution: 16 bits
Working voltage range: 2.7V to 5.5V
Output range: 0V to VREF
Maximum output accuracy: ± 1LSB
Output sampling rate: 1.25Msps
Low power consumption: 4mW (typical value)
Packaging: SOT-23
Working temperature range: -40 ° C to+125 ° C
Communication interface: SPI
Other characteristics: low drift, low noise, internal reference voltage, etc.
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| SVHC | Yes |
| Automotive | No |
| PPAP | No |
| Converter Type | General Purpose |
| Architecture | Resistor-String |
| Resolution | 12bit |
| Conversion Rate | 50ksps |
| Number of DAC Channels | 1 |
| Number of Outputs per Chip | 1 |
| Maximum Settling Time (us) | 10 |
| Digital Interface Type | Serial (2-Wire, I2C) |
| Output Type | Voltage |
| Output Polarity | Unipolar |
| Voltage Reference | External |
| Minimum Single Supply Voltage (V) | 2.7 |
| Power Supply Type | Single |
| Integral Nonlinearity Error | ±0.195%FSR |
| Full Scale Error | -1.25%FSR |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 105 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1.1 |
| Package Width | 1.75(Max) |
| Package Length | 3.05(Max) |
| PCB changed | 6 |
| Standard Package Name | SOT |
| Supplier Package | SOT-23 |
| Pin Count | 6 |
| Lead Shape | Gull-wing |
