Place of Origin:
original
Brand Name:
TI
Model Number:
DAC7512N
Contact Us
Application: DAC7512N is a 12 bit digital to analog converter (DAC) widely used in industrial automation, instrumentation, communication equipment, audio equipment, and other fields.
Conclusion: DAC7512N has the characteristics of high accuracy, low noise, low power consumption, and high speed, and can achieve high-performance analog output. At the same time, the chip has self calibration function, which can improve the reliability and stability of the system.
Parameters:
Resolution: 12 bits
Output voltage range: 0~Vref (Vref is the reference voltage)
Working voltage: 2.7V~5.5V
Output current: ± 5mA
Consumption current: 2.5mA
Update rate: 1.2MHz
DNL (differential nonlinearity): ± 1LSB
INL (integrated nonlinearity): ± 1LSB
Temperature range: -40 ℃~+105 ℃
Packaging form: SOT23-6
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| SVHC | Yes |
| Automotive | No |
| PPAP | No |
| Converter Type | General Purpose |
| Architecture | Resistor-String |
| Resolution | 12bit |
| Conversion Rate | 95ksps |
| Number of DAC Channels | 1 |
| Number of Outputs per Chip | 1 |
| Maximum Settling Time (us) | 10 |
| Digital Interface Type | Serial (3-Wire, SPI, QSPI, Microwire) |
| Output Type | Voltage |
| Output Polarity | Unipolar |
| Voltage Reference | External |
| Minimum Single Supply Voltage (V) | 2.7 |
| Power Supply Type | Single |
| Integral Nonlinearity Error | ±8LSB |
| Full Scale Error | -1.25%FSR |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 105 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1.1 |
| Package Width | 1.75(Max) |
| Package Length | 3.05(Max) |
| PCB changed | 6 |
| Standard Package Name | SOT |
| Supplier Package | SOT-23 |
| Pin Count | 6 |
| Lead Shape | Gull-wing |
