Place of Origin:
original
Brand Name:
TI
Model Number:
LMV612MM/LMV612MMX
Contact Us
LMV612MMX is an amplifier with the following parameters:
Power supply voltage range: 2.7V to 5.5V
Normally open amplifier gain: 10dB to 40dB
Maximum output current: 30mA
Normally open input resistance: 20k Ω
Working temperature range: -40 ° C to 85 ° C
This device is suitable for applications such as audio amplification, sensors, and signal transmission. Some of these applications and conclusions include:
Audio amplification: LMV612MMX can amplify audio signals, making them clearer and louder. This device is suitable for the design of audio amplifiers to enhance the sound quality of audio systems.
Sensor signal amplification: This amplifier can amplify the small signals generated by the sensor for easier detection and analysis. This is very useful when measuring temperature, pressure, light, and other physical quantities.
Signal transmission: LMV612MMX can also be used to transmit signals from one circuit to another to enhance signal strength and quality. This can help solve problems such as signal-to-noise ratio in signal transmission.
In summary, the LMV612MMX is a powerful amplifier suitable for various applications.
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.33.00.01 |
| Automotive | No |
| PPAP | No |
| Type | Low Power Amplifier |
| Manufacturer Type | Low Power Amplifier |
| Number of Channels per Chip | 2 |
| Rail to Rail | Rail to Rail Input/Output |
| Process Technology | BiCMOS |
| Maximum Input Offset Voltage (mV) | 5.5@5V |
| Minimum Single Supply Voltage (V) | 1.8 |
| Maximum Single Supply Voltage (V) | 5.5 |
| Maximum Input Offset Current (uA) | 0.009(Typ)@5V |
| Maximum Input Bias Current (uA) | 0.035@5V |
| Maximum Supply Current (mA) | 0.42@5V |
| Maximum Quiescent Current (mA) | 0.1(Typ) |
| Power Supply Type | Single |
| Typical Slew Rate (V/us) | 0.42@5V |
| Typical Input Noise Voltage Density (nV/rtHz) | 50@5V |
| Typical Voltage Gain (dB) | 100 |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.08@5V |
| Minimum PSRR (dB) | 100(Typ) |
| Minimum CMRR (dB) | 50 |
| Minimum CMRR Range (dB) | 50 to 60 |
| Typical Gain Bandwidth Product (MHz) | 1.5 |
| Shut Down Support | No |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Supplier Temperature Grade | Industrial |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 0.95(Max) |
| Package Width | 3.1(Max) |
| Package Length | 3.1(Max) |
| PCB changed | 8 |
| Standard Package Name | SOP |
| Supplier Package | VSSOP |
| Pin Count | 8 |
| Lead Shape | Gull-wing |
