Place of Origin:
original
Brand Name:
FAIRCHILD
Model Number:
LMV358AM8X
Contact Us
LMV358AM8X is a dual-channel, low-voltage operational amplifier (op-amp) integrated circuit (IC) manufactured by Texas Instruments. It is a general-purpose op-amp designed to operate with a single supply voltage, providing rail-to-rail input and output swing.
Applications:
Audio amplifiers and preamplifiers.
Sensor amplifiers.
Signal conditioning circuits.
Active filters.
Voltage-controlled oscillators.
Features:
Dual independent op-amps in a single package.
Wide input voltage range: 2.7V to 5.5V.
Rail-to-rail input and output swing.
Low power consumption: 0.5 mA per channel.
High common-mode rejection ratio (CMRR): 70 dB.
Low input bias current: 45 nA.
Unity-gain stable.
ESD protection: 2 kV (human body model).
Parameters:
Input voltage range: 2.7V to 5.5V.
Output voltage range: 0V to VCC.
Operating temperature range: -40°C to 125°C.
Gain bandwidth product: 1 MHz.
Slew rate: 0.5 V/μs.
Input offset voltage: 5 mV.
Input offset current: 2 nA.
Packaging: SOIC-8.
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Obsolete |
| HTS | 8542.33.00.01 |
| Automotive | No |
| PPAP | No |
| Type | Low Voltage Amplifier |
| Manufacturer Type | Low Voltage Amplifier |
| Number of Channels per Chip | 2 |
| Rail to Rail | Rail to Rail Output |
| Process Technology | CMOS |
| Output Type | CMOS |
| Maximum Input Offset Voltage (mV) | 7@5V |
| Minimum Single Supply Voltage (V) | 2.7 |
| Maximum Single Supply Voltage (V) | 5.5 |
| Minimum Dual Supply Voltage (V) | 卤1.35 |
| Maximum Dual Supply Voltage (V) | 卤2.75 |
| Maximum Input Offset Current (uA) | 0.001(Typ)@5V |
| Typical Input Bias Current (uA) | 0.001@5V |
| Maximum Supply Current (mA) | 0.3@5V |
| Typical Output Current (mA) | 160 |
| Power Supply Type | Single|Dual |
| Typical Slew Rate (V/us) | 1.5@5V |
| Typical Input Noise Voltage Density (nV/rtHz) | 33@5V |
| Typical Voltage Gain (dB) | 70 |
| Minimum PSRR (dB) | 50 |
| Minimum CMRR (dB) | 50 |
| Minimum CMRR Range (dB) | 50 to 60 |
| Typical Gain Bandwidth Product (MHz) | 1.4 |
| Shut Down Support | No |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1.5(Max) |
| Package Width | 3.9 |
| Package Length | 4.9 |
| PCB changed | 8 |
| Standard Package Name | SO |
| Supplier Package | SOIC |
| Pin Count | 8 |
| Lead Shape | Gull-wing |
Send your inquiry directly to us
