Place of Origin:
original
Brand Name:
ST
Model Number:
LMV324IPT
Contact Us
Application of LMV324IPT:
Laser rangefinder;
Electronic sphygmomanometer;
Temperature sensor;
Signal amplification of the circuit;
Filtering of circuits;
lighting;
Intelligent Home Furnishing system;
Vehicle control system.
Conclusion of LMV324IPT:
LMV324IPT is a low-voltage four way operational amplifier;
Suitable for single power supply systems;
There are four independent operational amplifiers;
With 1MHz Gain–bandwidth product, 0.6V/ μ The slope rate of s;
Having a low input bias current of 10nA and a low input offset voltage of 3mV;
It can be used in applications such as active filters, instrument amplifiers, and signal conditioning circuits.
Parameters of LMV324IPT:
Power supply voltage: 2.7V-5.5V;
Gain–bandwidth product: 1MHz;
Slope rate: 0.6V/ μ s；
Input bias current: 10nA;
Input offset voltage: 3mV;
Working temperature range: -40 ℃ to+125 ℃;
Packaging type: TSSOP14
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.33.00.01 |
| Automotive | No |
| PPAP | No |
| Type | Low Voltage Amplifier |
| Manufacturer Type | Low Voltage Amplifier |
| Number of Channels per Chip | 4 |
| Rail to Rail | Rail to Rail Input/Output |
| Maximum Input Offset Voltage (mV) | 3@5V |
| Minimum Single Supply Voltage (V) | 2.7 |
| Maximum Single Supply Voltage (V) | 6 |
| Maximum Input Offset Current (uA) | 0.009@5V |
| Typical Input Bias Current (uA) | 0.016@5V |
| Maximum Input Bias Current (uA) | 0.063@5V |
| Maximum Quiescent Current (mA) | 0.88@5V |
| Typical Output Current (mA) | 48@5V |
| Power Supply Type | Single |
| Typical Slew Rate (V/us) | 0.45@5V |
| Typical Input Noise Voltage Density (nV/rtHz) | 40@5V |
| Typical Voltage Gain (dB) | 97 |
| Minimum CMRR (dB) | 65 |
| Minimum CMRR Range (dB) | 65 to 70 |
| Typical Gain Bandwidth Product (MHz) | 1.3 |
| Shut Down Support | No |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1 |
| Package Width | 4.4 |
| Package Length | 5 |
| PCB changed | 14 |
| Standard Package Name | SOP |
| Supplier Package | TSSOP |
| Pin Count | 14 |
| Lead Shape | Gull-wing |
