Place of Origin:
original
Brand Name:
STMICROELECTRONICS
Model Number:
LMV321LICT
Contact Us
LMV321LICT is a low-power, single operational amplifier (op-amp) IC from Texas Instruments. It has a voltage range of 2.7V to 5.5V and a low input bias current of 30nA. This op-amp is designed for low-power applications such as battery-powered devices and portable electronics. It has a unity-gain bandwidth of 1MHz and a slew rate of 0.5V/µs. The LMV321LICT is available in a SOT-23-5 package and is RoHS compliant.
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.33.00.01 |
| Automotive | No |
| PPAP | No |
| Type | Low Power Amplifier |
| Manufacturer Type | Low Power Amplifier |
| Number of Channels per Chip | 1 |
| Rail to Rail | Rail to Rail Output |
| Maximum Input Offset Voltage (mV) | 7@5V |
| Minimum Single Supply Voltage (V) | 2.7 |
| Maximum Single Supply Voltage (V) | 5.5 |
| Typical Low Level Output Voltage (V) | 0.3 |
| Typical High Level Output Voltage (V) | 4.99 |
| Maximum Input Offset Current (uA) | 0.03@5V |
| Typical Input Bias Current (uA) | 0.027@5V |
| Maximum Input Bias Current (uA) | 0.06@5V |
| Maximum Quiescent Current (mA) | 0.25@5V |
| Power Supply Type | Single |
| Typical Slew Rate (V/us) | 0.7@5V |
| Typical Input Noise Voltage Density (nV/rtHz) | 30@5V |
| Input Offset Voltage Drift (uV/°C) | 5(Typ) |
| Typical Voltage Gain (dB) | 100 |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.3@5V |
| Minimum CMRR (dB) | 72 |
| Minimum CMRR Range (dB) | 71 to 75 |
| Typical Gain Bandwidth Product (MHz) | 1.3 |
| Shut Down Support | No |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Supplier Temperature Grade | Industrial |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 0.9 |
| Package Width | 1.25 |
| Package Length | 2 |
| PCB changed | 5 |
| Standard Package Name | SOT |
| Supplier Package | SC-70 |
| Pin Count | 5 |
| Lead Shape | Gull-wing |
