Place of Origin:
original
Brand Name:
Skyworks
Model Number:
570AAC000118DG
Contact Us
570AAC000118DG New And Original SMD Integrated Circuit
570AAC000118DG is an SMT mount model thin film capacitor. The following are the main parameters of 570AAC000118DG:
Rated capacitance: 1.8pF
Rated voltage: 100V
Tolerance: ± 0.5pF
Operating temperature range: -55 ° C to+125 ° C
Packaging: SMT mounting
The following are some applications of 570AAC000118DG:
RF circuit: Due to its small capacitance value and high-precision tolerance, 570AAC000118DG is commonly used in RF circuits, such as antennas, filters, and resonators.
Communication equipment: 570AAC000118DG can also be used for frequency control circuits and clock circuits in communication equipment.
Test and measurement: because of its high precision, 570AAC000118DG can also be used for frequency meter, spectrum analyzer, etc. in test and measurement equipment.
Conclusion: 570AAC000118DG is an SMT mounted thin film capacitor suitable for RF circuits, communication equipment, and testing and measurement fields. It has a small capacitance value and high-precision tolerance, which can improve the stability and accuracy of the circuit.
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Automotive | No |
| PPAP | No |
| Type | Programmable Crystal Oscillator |
| Standard Frequency (MHz) | 156.25 |
| Frequency Stability (ppm) | ±61.5 |
| Frequency Aging (ppm/Year) | ±3 (1st) |
| Maximum Symmetry (%) | 55 |
| Output Level | LVPECL |
| Minimum Operating Supply Voltage (V) | 2.97 |
| Maximum Operating Supply Voltage (V) | 3.63 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Mounting | Surface Mount |
| Package Height | 1.65 |
| Package Width | 5 |
| Package Length | 7 |
| PCB changed | 8 |
| Pin Count | 8 |
| Lead Shape | No Lead |
