Place of Origin:
original
Brand Name:
STMICROELECTRONICS
Model Number:
STM32H7A3LIH6Q
Contact Us
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | 3A991a.2. |
| Part Status | Active |
| HTS | 8542.31.00.01 |
| Automotive | No |
| PPAP | No |
| Family Name | STM32 |
| Instruction Set Architecture | RISC |
| Device Core | ARM Cortex M7 |
| Core Architecture | ARM |
| Maximum CPU Frequency (MHz) | 280 |
| Maximum Clock Rate (MHz) | 280 |
| Data Bus Width (bit) | 32 |
| Program Memory Type | Flash |
| Program Memory Size | 2MB |
| RAM Size | 1380KB |
| Programmability | Yes |
| Process Technology | 40nm |
| Interface Type | CAN/I2C/I2S/SPI/UART/USART/USB |
| Number of I/Os | 168 |
| No. of Timers | 15 |
| Number of ADCs | Dual |
| ADC Channels | 24/24 |
| ADC Resolution (bit) | 16/16 |
| Number of DACs | Dual |
| DAC Channels | 3/3 |
| DAC Resolution (bit) | 12/12 |
| USART | 5 |
| UART | 6 |
| USB | 1 |
| SPI | 6 |
| I2C | 4 |
| I2S | 4 |
| CAN | 2 |
| Ethernet | 0 |
| Minimum Operating Supply Voltage (V) | 1.62 |
| Typical Operating Supply Voltage (V) | 1.8|2.5|3.3 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Minimum Operating Temperature (C) | -40 |
| Maximum Operating Temperature (C) | 85 |
| Supplier Temperature Grade | Industrial |
| Packaging | Tray |
| Mounting | Surface Mount |
| Package Height | 0.76 |
| Package Width | 13 |
| Package Length | 13 |
| PCB changed | 225 |
| Supplier Package | TFBGA |
| Pin Count | 225 |
