Place of Origin:
original
Brand Name:
MICROCHIP
Model Number:
KSZ9031RNXIC
Contact Us
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | 5A991b. |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| Automotive | No |
| PPAP | No |
| Number of Channels per Chip | 1 |
| Maximum Data Rate | 1Gbps |
| PHY Line Side Interface | No |
| JTAG Support | No |
| Integrated CDR | No |
| Standard Supported | 10BASE-T|100BASE-TX|1000BASE-T|IEEE 802.3 |
| Typical Data Rate (MBps) | 10/100/1000 |
| Ethernet Speed | 10Mbps/100Mbps/1000Mbps |
| Ethernet Interface Type | RGMII |
| Minimum Operating Supply Voltage (V) | 1.14|1.71|2.375|3.135 |
| Typical Operating Supply Voltage (V) | 1.8|2.5|3.3 |
| Maximum Operating Supply Voltage (V) | 1.38|1.89|2.625|3.465 |
| Maximum Supply Current (mA) | 221(Typ) |
| Power Supply Type | Analog|Digital |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Supplier Temperature Grade | Industrial |
| Packaging | Tray |
| Mounting | Surface Mount |
| Package Height | 0.85(Max) |
| Package Width | 7 |
| Package Length | 7 |
| PCB changed | 48 |
| Standard Package Name | QFN |
| Supplier Package | VQFN EP |
| Pin Count | 48 |
| Lead Shape | No Lead |
