Place of Origin:
original
Model Number:
HMC311SC70E
Contact Us
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.33.00.01 |
| Automotive | No |
| PPAP | No |
| Manufacturer Type | Gain Amplifier |
| Number of Channels per Chip | 1 |
| Maximum Operating Frequency (MHz) | 8000 |
| Typical Power Gain (dB) | 13@8000MHz |
| Typical Output Power (dBm) | 11@8000MHz |
| Typical Output Intercept Point (dBm) | 24@8000MHz |
| Maximum Reverse Isolation (dB) | 18(Typ)@8000MHz |
| Maximum Input Return Loss (dB) | 15(Typ)@8000MHz |
| Maximum Output Return Loss (dB) | 15(Typ)@8000MHz |
| Typical Noise Figure (dB) | 5@8000MHz |
| Maximum Operating Supply Voltage (V) | 7 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Single Supply Voltage (V) | 7 |
| Maximum Supply Current (mA) | 74@5V |
| Power Supply Type | Single |
| Maximum Power Dissipation (mW) | 340 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 0.91(Max) |
| Package Width | 1.35(Max) |
| Package Length | 2.25(Max) |
| PCB changed | 6 |
| Standard Package Name | SOT |
| Supplier Package | SC-70 |
| Pin Count | 6 |
| Lead Shape | Gull-wing |
