Place of Origin:
original
Brand Name:
NXP
Model Number:
FS32K116LAT0MLFT
Contact Us
| Product Properties | ||
| type | describe | |
| classification | Integrated Circuit (IC) | |
| Embedded | ||
| micro controller | ||
| manufacturer | NXP USA Inc. | |
| series | S32K | |
| packing | Tray | |
| Product Status | On sale | |
| Core processor | ARM® Cortex®-M0+ | |
| Kernel specifications | 32-bit single core | |
| speed | 48MHz | |
| Connectivity | CANbus,FlexIO,I²C,LINbus,SPI,UART/USART | |
| peripheral | DMA,PWM,WDT | |
| Number of I/Os | 43 | |
| Program storage capacity | 128KB(128K x 8) | |
| Program memory type | Flash Memory | |
| EEPROM capacity | 2K x 8 | |
| RAM size | 17K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V | |
| Data converter | A/D 13x12b SAR; D/A 1x8b | |
| Oscillator type | 内部 | |
| working temperature | -40°C ~ 125°C(TA) | |
| Installation type | Surface Mount | |
| Package/Enclosure | 48-LQFP | |
| Supplier Device Packaging | 48-LQFP(7x7) | |
| Basic Product Number | FS32K116 | |
| Resource Type | interlinkage | |
| Specification | S32K1xx | |
| S32K1xx Product Brief | ||
| S32K1xx Series Reference Manual | ||
| Environmental Information | NXP USA Inc REACH | |
| NXP USA Inc RoHS Cert | ||
| Featured Products | S32K116/K118 Automotive-Qualified MCUs | |
| Ticket Vending Machine | ||
| PCN Design/Specification | S32K1xx 18/Nov/2021 | |
| S32K1xx 13/Mar/2020 | ||
| PCN assembly/source | Mult Dev A/T Site 28/Apr/2021 | |
| PCN packaging | Mult Dev Pkg Seal 15/Dec/2020 | |
| All Dev Label Update 15/Dec/2020 | ||
| HTML Specification | S32K1xx Product Brief | |
| Environmental and Export Classification | ||
| attribute | describe | |
| RoHS Status | Comply with ROHS3 specifications | |
| Moisture Sensitivity Level (MSL) | 3 (168 hours) | |
| REACH status | Non REACH products | |
| ECCN | 5A992C | |
| HTSUS | 8542.31.0001 | |
| attribute | describe | |
| Other names | 9.35376E+11 | |
| 568-14729 | ||
| Standard packaging | 250 |
