ADS8688IDBR is a high-precision and high-speed 8-channel analog-to-digital converter, with the following main parameters:
Resolution: 16 bits
Sampling rate: 500kSPS
Working voltage range: 2.7V to 5.5V
Working temperature range: -40 ℃ to 105 ℃
Packaging: SSOP-38
The following are some applications of ADS8688IDBR:
Industrial automation: ADS8688IDBR can be used for data collection, process control, and monitoring in industrial automation.
Medical equipment: Due to its high precision and high-speed sampling rate, ADS8688IDBR can also be used for biological signal acquisition, medical image processing, and other applications in medical equipment.
Communication equipment: ADS8688IDBR can also be used for signal acquisition, modulation and demodulation in communication equipment.
Conclusion: ADS8688IDBR is a high-precision and high-speed analog-to-digital converter suitable for various application scenarios such as industrial automation, medical equipment, communication equipment, etc. It has high resolution, high-speed sampling rate, and a wide operating voltage range, which can meet the needs of different application scenarios. Its packaging is SSOP-38, suitable for SMT mounting.
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| SVHC | Yes |
| Automotive | No |
| PPAP | No |
| Converter Type | General Purpose |
| Architecture | SAR |
| Resolution | 14bit |
| Number of ADCs | 1 |
| Number of Input Channels | 8 |
| Sampling Rate | 500ksps |
| Digital Interface Type | Serial (SPI) |
| Input Type | Voltage |
| Input Signal Type | Single-Ended |
| Voltage Reference | Internal|External |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Voltage Supply Source | Analog and Digital |
| Input Voltage | 1.28V/2.56V/5.12V/10.24V|±0.64V/±1.28V/±2.56V/±5.12V/±10.24V |
| Minimum Single Supply Voltage (V) | 4.75 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Single Supply Voltage (V) | 5.25 |
| Integral Nonlinearity Error | ±0.75LSB |
| Full Scale Error | ±0.05%FSR |
| Signal to Noise Ratio | 85dB(Typ) |
| No Missing Codes (bit) | 14 |
| Sample and Hold | Yes |
| Single-Ended Input | Yes |
| Digital Supply Support | Yes |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Packaging | Tape and Reel |
| Supplier Temperature Grade | Industrial |
| Mounting | Surface Mount |
| Package Height | 1.05(Max) |
| Package Width | 4.5(Max) |
| Package Length | 9.8(Max) |
| PCB changed | 38 |
| Standard Package Name | SOP |
| Supplier Package | TSSOP |
| Pin Count | 38 |
| Lead Shape | Gull-wing |
