Place of Origin:
original
Brand Name:
Intel/Altera
Model Number:
5CSXFC5C6U23C7N
Contact Us
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| Automotive | No |
| PPAP | No |
| Family Name | Cyclone庐 V SX |
| Process Technology | 28nm |
| User I/Os | 124 |
| Operating Supply Voltage (V) | 1.1 |
| Shift Registers | Utilize Memory |
| Logic Elements | 85000 |
| Number of Multipliers | 174 (18x19) |
| Program Memory Type | SRAM |
| Embedded Memory (Kbit) | 3972 |
| EMACs | 2 |
| Device Logic Units | 85000 |
| Number of Global Clocks | 16 |
| Device Number of DLLs/PLLs | 6 |
| Transceiver Channels | 9 |
| JTAG Support | Yes |
| Transceiver Speed (Gbps) | 3.125 |
| Dedicated DSP | 87 |
| PCIe | 2 |
| Programmability | Yes |
| Reprogrammability Support | Yes |
| Copy Protection | No |
| In-System Programmability | Yes |
| Speed Grade | 7 |
| Differential I/O Standards | LVDS|LVPECL |
| Single-Ended I/O Standards | LVCMOS|LVTTL |
| External Memory Interface | LPDDR2|DDR3 SDRAM|DDR2 SDRAM |
| Minimum Operating Supply Voltage (V) | 1.07 |
| Maximum Operating Supply Voltage (V) | 1.13 |
| I/O Voltage (V) | 3.3|3|2.5|1.8|1.5|1.35|1.25|1.2 |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 85 |
| Supplier Temperature Grade | Commercial |
| Tradename | Cyclone |
| Mounting | Surface Mount |
| Package Height | 1.3 |
| Package Width | 23 |
| Package Length | 23 |
| PCB changed | 672 |
| Standard Package Name | BGA |
| Supplier Package | UFBGA |
| Pin Count | 672 |
| Lead Shape | Ball |
